2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

Brand Name : TYF

Model Number : TS1-P28FA-XXXXXX-XXXXX-XX

Place of Origin : China

Certification : CE,RoHS,LM80,IEC\EN62471

MOQ : 20Kpcs

Price : Please Contact Sales Team

Packaging Details : Please Contact Sales Team

Delivery Time : 15-20workdays

Payment Terms : T/T

Supply Ability : 3KK-5KK/Day

Luminous Efficiency : 155-190lm/w

Forward Current : 20-300mA

Typical Wattage : 1W

Cri : Ra70, Ra80, Ra90

Operating Temperature : -40 To 85 Degrees Celsius

Storage Temperature : -40 To 100 Degrees Celsius

Contact Now

Dimensions:

All dimensions area in mm tolerance is ±0.2mm unless otherwise noted.

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

Technical Parameters:

Optional Luminous Efficiency range: 155-190lm/w
Type SMD 2835 LED
Typical Wattage 1W
Conventional optional correlated color temperature range 2700K-6500K
Package Material PCT
Package Quantity 4000 pcs per Reel
Optional Forward Current 20-300mA
Others: If you need datasheet for better or lower light efficiency ranges, please contact the Sales team.

Applications:

● Outdoor general lighting
● Industrial lighting
● Professional downlights
● Retrofits and fixtures

Electrical and Optical characteristics(Tj=25℃):

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM

2835 LED Chip 3v 0.5W-1W 190Lm/w with 5SDCM
